Xiaomi May Launch a Smartphone With an Internal Flip Camera. Closing month, xiaomi patented a brand new cellphone with a unique digital camera design. The patent revealed a handset with a digicam module that had a thunderbolt-like layout at the rear facet. The patent turned into filed by way of the chinese phone maker returned in october 2020, which became posted last month on april twentieth, 2021.
Now, oldsters at LetsgoDigital has determined but some other exciting patent by means of xiaomi. As according to the info published by way of LetsgoDigital, xiaomi has patented a telephone with a rotating below-display digital camera. This patent turned into filed by xiaomi again in february 2020 with international intellectual belongings corporation (wipo). Permit’s check more details on this ahead:
As in line with letsgodigital, this new xiaomi patent published through wipo on april 29, 2021. The patent in quick reveals how xiaomi plans to integrate an internally rotating camera into a telephone.
The patented device capabilities an under-show selfie digicam. The below-show selfie digital camera tech already validated via xiaomi back in august 2020. If we pass through the preceding statistics, xiaomi plans to announce smartphones ready with the 3rd generation under-show digital camera in 2021.
The business enterprise already had confirmed that it’ll be starting the production of the below-show cameras this year. With the new patent submitting, we do get an concept. It told us how the organization plans to collect an internally rotating digital camera into a telephone.
Xiaomi May Launch a Smartphone With an Internal Flip Camera
If we move by way of the patent information discovered via wipo, we can see that a turn camera module is placed behind the display screen, with at the least one camera lens.
The camera via default is faces the rear, and is part of a larger camera module that includes numerous lenses. If we got a look on the photos below, we can see that best the top lens of the triple digicam setup (proven in orange) rotatable, while the other lenses remain intact on the rear.
The top digicam lens may circled at the front facet by means of a magnet or a motorized force module and a processor. While the selfie digital came activated at the front, the show element across the camera module will disable so that it will permit in sufficient ambient light.
Based at the documentation information by wipo, xiaomi may prefer a magnetic module, for the turn digital camera mechanism. The closing image demonstrates the module which shall manage this turn digital camera mechanism.
